Are you still troubled by purchasing the Allen Bradley 2711-K5A20L2 module? Hannit is well aware of your pain points: inability to find stock, high prices, and no after-sales guarantee. We will solve all your problems and provide a one-stop solution, allowing you to easily obtain the modules you need and focus on your core business with peace of mind!
|
Module |
Allen Bradley 2711-K5A20L2 |
|
Display |
5.5-inch Monochrome LCD |
|
|
Resolution: 320 × 240 pixels (QVGA) |
|
|
Display Mode: Blue background with white text |
|
Input Method |
20 Membrane Function Keys |
|
|
Numeric Keypad |
|
|
Navigation Keys |
|
Power Supply |
18-32 VDC |
|
|
Typical Power Consumption: 11W |
|
Communication Ports |
DH-485 (A-B proprietary 8-pin round port) |
|
|
RS232 Programming Port |
|
Memory |
170 KB Application Memory (approx. 100 screens) |
|
Operating Temperature |
0 °C to 55 °C (32 °F to 131 °F) |
|
Protection Rating |
IP65 (Front Panel, when mounted in an enclosure door) |
|
Dimensions (H × W × D) |
167 mm × 215 mm × 58 mm (6.58 in. × 8.46 in. × 2.28 in.) |
|
|
Includes mounting clips |
|
Weight |
1.4 kg (3.09 lbs) |
Municipal water dosing systems, small-scale sewage treatment plants, grain dryers, injection molding machines, textile printing and dyeing setting machines, concrete mixing plants - almost all small and medium-sized projects that use SLC500 or MicroLogix are using Allen Bradley 2711-K5A20L2.
The AB 2711-K5A20L2 is developed with PanelBuilder32 and supports ladder diagram labels, alarm lists, message display, multi-status indicator lights, numerical input and output, and recipe management. The most practical part is that simple parameter modifications can be made directly on the terminal without having to turn on the laptop. It supports printing alarm history to serial port printers. Some factories are still using this function to make paper records.
