Siemens 6GK5302-7GD00-2EA3

Siemens 6GK5302-7GD00-2EA3 is an industrial Ethernet communication processor (CP) designed for SIMATIC S7-300 PLC, which can realize high-speed and reliable Ethernet connection and PROFINET communication. Hanyite Automation Technology always adheres to the principle of "quality first, service first" and takes "quality assurance, conscientious pricing, and enthusiastic service" as its purpose, and is committed to becoming your most trusted partner. If you are interested in this powerful communication processor and are eager to improve the network communication capabilities of your industrial automation system, please contact us immediately, let us work together to open a new chapter of cooperation and create a better future!

Function

Siemens 6GK532-7GD00-2EA3 supports all grades of PROFINET CCA/B/C, and the IRT synchronization accuracy can reach ±30μs. Dual backup of ring network protocol MRP+HRP, with automatic switching of the cut-off interface less than 20ms. All the functions such as port mirroring, traffic statistics, and port security binding to MAC addresses are available. You can manage it as you like using Web, CLI, TIA Portal or SINEMA Server. Just insert the SD card and the entire configuration can be copied to the new machine. It only takes a few minutes to change the machine on the spot.

Parameter

Features

6GK5302-7GD00-2EA3 Siemens with three layers of Coating (Extended Environmental Coating), in coastal, chemical, steel plants such as salt spray, hydrogen sulfide places can be used for 5-8 years, the shell is completely rust free. All seven electrical ports are made of RJ45 metal shells and will not loosen even after being plugged and unplugged over 1,000 times. Two Gigabit SFP cages support both multi-mode and single-mode insertion, with a maximum distance of up to 120 kilometers. The front panel has a separate CONSOLE port, which can be connected to a computer for Settings with a regular network cable, making on-site debugging particularly convenient.
