Siemens 6ES7153-2AB00-0XB0

In China, Hanyite provides new and old customers with Siemens 6ES7153-2AB00-0XB0 as a bridge between the ET 200M station and the PROFIBUS DP master station, responsible for two-way data communication. In addition to the listed products, if you are looking for other models, please contact us.

Parameter

Product Series: ET 200M

Interface type: PROFIBUS DP

Communication rate: 9.6 Kbps... 12 Mbps

Supply voltage: 24V DC

Protection grade: IP20

Configuration software: STEP 7

Module quantity: 8

Advantages and features

Siemens 6ES7153-2AB00-0XB0 , as a slave device of PROFIBUS, can flexibly configure various I/O modules through data exchange based on actual conditions. It supports hot-swapping operations during system operation and allows for the replacement or addition of signal and functional modules of S7-300. It supports the realization of multi-slave station output signal synchronization and freezing mode, and has rich diagnostic information. SF/BF LED indicator lights can be integrated.

Application features

Siemens 6ES7153-2AB00-0XB0 is frequently used in the industrial field. Control of robots and signal acquisition of workstation sensors; The classification of stereoscopic warehouses, conveyor belts of sorting lines and stackers in warehouses; Centralized monitoring of scattered pumps, valves and instruments in chemical plants and water treatment plants.

FAQ

What model alternatives are there for this module?

PROFINET's ET 200SP or ET 200MP system. You can contact us to check the inventory or the officially recommended alternative models.

How to set the PROFIBUS address for IM 153-2?

There is a rotary switch on the top of Siemens 6ES7153-2AB00-0XB0. You can use a small screwdriver to rotate it to any number between 0 and 99.
